For temperature control of samples in baths or for enclosed external instruments such as refractometers, polarimeters, photometers, viscosimeters, electrophoresis chambers, chromatography columns and rotary evaporators.
Type | CORIO™ CD-200F |
Operating temperature | -20 to +150 °C |
Temperature constancy | ±0,03 K |
Display resolution | 0,1 °C |
Setting resolution | 0.1 °C |
Heating output | 2000 W |
Cooling capacity | 20 °C: 220 W 0 °C: 170 W -20 °C: 60 W |
Max. pump pressure | 350 mbar |
Max. flow | 15 l/min |
Bath volume | 3-4 l |
Bath opening | 130 x 150 mm |
Inner depth | 150 mm |
Outer width | 230 mm |
Outer depth | 390 mm |
Outer height | 650 mm |
Safety class | III (FL) |
Mains connection | 230 V, 50 Hz |
