With pressure- and chemical-resistant housing made of PP, housing ultrasonically welded (filter with membrane Ø 15 mm) or injection-moulded (filter with membrane Ø 25 and 30 mm).
Sterile version (individually packed) available as an option.
Hydrophobic membrane for the filtration of aggressive chemicals, acids and non-polar solvents. Low flow resistance to gases, can therefore also be used for air and gas filtration (e.g. for aeration and ventilation work and for sterile gas exchange).
Pore size | 0,2 µm |
Sterility | Sterile |
Ø membrane | 25 mm |
Colour coding | magenta |
Ø Housing | 30 mm |
Membrane material | hydrophobic PTFE |
Housing material | PP |
Sample volume | 10–100 ml |
Dead volume | <65 µl |
Total filter volume | 0.6 ml |
Filtration area | 4.9 cm² |
Max. operating pressure | 7 bar |
Inlet connection | Luer lock connector |
Outlet connection | Luer connector |
