Range of applications:
Colour code: red. For dispensing aggressive reagents directly from the supply bottle, e.g. concentrated bases and acids such as H3PO4, H2SO4 (excluding, e.g., HCI, HNO3 and HF), saline solutions and a wide range of organic solvents.
Materials in contact with media:
borosilicate glass, Al2O3 ceramic, platinum-iridium, ETFE, FEP, PFA, PTFE and PP.
Limits of use:
max. vapour pressure 600 mbar; max. viscosity 500 mm2/s; max. temperature +40 °C; max. density 2.2 g/cm3.
Non-adjustable dispensing volume for routine applications.
Discharge tube with recirculation valve prevents reagent loss and allows quick, bubble-free ventilation.
Volume | 2 ml |
Nominal volume | 2 ml |
Correctness | ±10 µl |
Variation coefficient | ±2 µl |
Operating temperature | +15 - +40 °C |
Adapter | GL 24-25, GL 28/S 28, GL 32-33, GL 38, S 40 |
Suction tube length | 240 mm |
